Cambodia 25m High Mast Lighting (2024)
25 m high-mast poles installed for wide-area lighting with 80W LED floodlights.
Designed for tender clarity: drawings on request, aiming notes, and sign-off checks for EPC teams.
Project Background
This Cambodia deployment uses 25 m high-mast poles to cover wide-area zones where uniform visibility matters. The configuration focuses on repeatable aiming, clear drawings for installation alignment, and practical acceptance checks—so EPC teams can commission multiple masts with consistent results and defensible sign-off records.
Technical Configuration (Typical Range)
✓25 m high mast structure matched to site wind and foundation constraints
✓80W LED floodlights for wide-area coverage (beam options for zone aiming)
✓Aiming direction recorded per mast to reduce glare and dark spots (notes available)
✓Cable routing, grounding path, and cabinet protection aligned to site environment
✓Drawings pack can be shared on request (GA / foundation interface / bolt circle)
✓Acceptance checklist supports repeatable commissioning and traceable sign-off
Scope & Assumptions
A concise summary of what this reference covers and the verification inputs behind it.
Scope
- 25 m high mast lighting supply for wide-area coverage (site / yard / interchange use)
- 80W LED floodlights per luminaire, matched aiming approach for zone uniformity
- Electric lowering system supported for safer maintenance access and repeatable service workflow
- Documentation support: drawings pack + deliverables list available on request (NDA if required)
- Verification logic: assumptions, interface notes, and acceptance checklist for EPC sign-off
Assumptions (for verification)
- Site geometry and coverage zones follow project BOQ / layout notes (mast locations and service access)
- Target performance is verified by photometry + documented aiming direction per mast (to reduce dark spots & glare)
- Electrical protection level is defined by site environment and grounding conditions (cabinet SPD / earthing path)
- Electric lowering system is validated by functional test and safety locking/limit checks at commissioning
- Final configuration is confirmed against submitted drawings and revision table prior to shipment
Detailed verification inputs can be shared in a redacted pack or under NDA for tender review.
Photos & Acceptance Notes
Field photos confirm the deployment is real. The notes below summarize typical site acceptance checks used by EPC teams to reduce rework and sign-off risk.
Deliverables Provided
Reference deliverables available for tender review and verification. Browse samples in the resource pages or request a project-ready pack.
IES / LDT Photometric Files
Browse IES files used for roadway optics verification and layout checks. Suitable for EPC submissions and audit trails.
BOQ (Bill of Quantities)
Review BOQ examples aligned to scope, accessories, and configuration ranges for procurement and budgeting.
Drawings & Acceptance Checklist
Download or request CAD drawings, installation details, and datasheets for approvals.
DIALux / Relux Outputs
See report samples and typical verification items (maintained lux, uniformity, assumptions, and result tables).
FAQ (Tender & Verification)
Quick answers to common EPC / tender questions for this reference.
What documents can be shared for tender submission?
Typical tender pack can include GA drawings, foundation/bolt circle interface notes, cable routing notes, and an acceptance checklist.
A redacted version is available, and full records can be shared under NDA if required.
Do you provide photometry and aiming notes for verification?
Yes. For high mast projects, verification usually depends on documented assumptions and aiming directions per mast/zone.
Photometry and an aiming note table can be provided on request to support consultant review.
How is the electric lowering system verified for safety?
Commissioning checks include winch function, locking/limit verification, steel rope condition, anti-fall measures,
and operational steps for maintenance access. Records can be shared as part of a sign-off checklist.
Can you share photos and acceptance records under NDA?
Yes. We can provide site photos, packing list/serial tracking, inspection records, and commissioning notes in a redacted pack.
Full documentation is available under NDA for EPC and consultant verification.
What inputs do you need to propose a similar high mast configuration?
Share pole height, area type and dimensions, target requirements (or tender spec), power supply details,
and any preferred optics/beam constraints. If you have a layout sketch or BOQ, we can match a configuration range and deliverables list.
