Coordinate mast locations, height, optics, wind loads, foundation interfaces and maintenance around your site conditions.
Share the available layout and review requirements to identify the next engineering step.
APPLICATION CONTEXT
Large-area lighting application.
Compare the mounting strategy and the light distribution against the same site requirements.
High mast and conventional poles are mounting strategies. Floodlighting is not a mutually exclusive third system. No option is universally better; the decision depends on project geometry and engineering review.
Send what is available now. Mark unresolved items clearly so preliminary assumptions are not mistaken for confirmed specifications.
| Input category | Available now | Confirm during engineering review |
|---|---|---|
| Site / Area | Location, site plan, dimensions, activity zones and known obstacles. | Calculation boundaries, permitted mast positions, underground constraints and access routes. |
| Lighting Criteria | Applicable specification and any stated lux, uniformity, glare or spill-light criteria. | Agreed assessment zones, calculation basis and acceptance method. |
| Mast | Preferred height or positions, if specified; existing or new installation. | Candidate height, arrangement, luminaire count and maintenance interface. |
| Wind / Structural | Available wind basis, applicable standard and geotechnical information. | Design basis, installed loads, civil interface and required local approvals. |
| Electrical | Available voltage/frequency, supply location and operating requirements. | Cabinet scope, feeder/cable interfaces, protection, grounding and controls. |
| Maintenance | Available access, local capability and lowering or crane preference. | Service procedure, exclusion/access needs, inspection and spare-parts scope. |
| Procurement / Documents | Tender, BOQ, review stage and requested files. | Configuration, compliance/deviation record, document revisions and supply responsibilities. |
Changing one variable can change the lighting result, installed loads and service requirements.
Define working zones and boundaries.
Review obstacles and service access.
Compare complete mounting options.
Coordinate fixtures and installed loads.
Direct light toward the agreed zones.
Check the criteria and iterate.
APPLICATION CONTEXT
Review mast positions against working zones and access routes.
Compare candidate layouts against the same geometry, target zones and acceptance criteria. Review obstacles, sightlines, boundaries and maintenance corridors before selecting mast positions.
A change in luminaire count, headframe or aiming arrangement may require the lighting and structural assumptions to be reviewed again. Record the selected configuration and the assumptions still open.
Historical mast heights demonstrate delivered configurations only. They do not establish a universal height, spacing, coverage or performance requirement.
Coordinate the lighting arrangement with the structural design basis and the site-specific civil design.
Sunlurio can support system and document coordination within the agreed project scope. Structural design, civil responsibility and local approval duties must be confirmed for the project. A foundation reference supports coordination; it is not a universal construction design. Final details follow the confirmed system, site inputs and applicable approval process.
STRUCTURAL / FOUNDATION CONTEXT
Coordinate the base, anchor bolts and civil interface for the project.
A calculation is useful only when its geometry, photometric files and selected configuration match the project.
| Review check | Required basis | Review output |
|---|---|---|
| Target area | Site geometry, working zones, obstacles and boundary conditions. | Defined calculation areas and locations that require separate review. |
| Illuminance & uniformity | Project criteria, maintenance factor and calculation basis. | Average/minimum illuminance and uniformity assessed against the agreed requirements. |
| Beam selection & aiming | Selected luminaire, optic, quantity, position and mounting height. | Distribution and aiming schedule coordinated with the intended target zones. |
| Glare & spill | Driver/operator sightlines, sensitive boundaries and project limits. | Identify potential conflicts and review alternatives where needed. |
| DIALux / Relux model | Project geometry and IES/LDT matched to the selected luminaire, optic and BOM. | A project-specific report with traceable assumptions and configuration. |
TECHNICAL CONTEXT
Illustrative review context; not an approved project calculation.
BOQ / configuration → luminaire and optic → matched IES / LDT → calculation model → report and aiming schedule.
Use the approved aiming references when installing and servicing luminaires. Record deviations between the installed arrangement and the reviewed model before acceptance.
Preliminary calculations support option screening. Results remain specific to the reviewed project and configuration; they are not a performance guarantee for another site.
Confirm how the system will be powered, controlled, inspected and serviced before the configuration is frozen.
Evaluate ground-level service against the selected lowering equipment, operating procedure and safety controls. Confirm who can operate and inspect the system and what clear working area is needed.
Evaluate crane or other approved access against site access, exclusion zones, operating capability and service scheduling. Confirm the method before ordering; lowering is not universally required.
Control features and maintenance procedures depend on the selected architecture and agreed scope. Do not assume every configuration includes the same functions.
MAINTENANCE / OPERATION CONTEXT
Confirm the maintenance access method and operating responsibilities.
Compare offers against the same confirmed system and document basis—not mast height or total wattage alone.
| Project stage | Engineering input | Action / output / document | What must be confirmed |
|---|---|---|---|
| 01 · Preliminary Review | Available site plan, application, targets, constraints and requested documents. | Review the available basis; identify missing inputs, candidate system direction and the next review step. | Geometry, performance criteria and design responsibilities may remain open. Initial assumptions are not a fixed specification. |
| 02 · Engineering Development | Confirmed review basis; candidate layout, luminaire/optic, wind and civil inputs. | Coordinate photometric review, aiming, mast/interface drawings, electrical scope and configuration. Request model-matched documents. | Resolve the agreed design basis, configurations, interfaces, responsibilities and document revisions. |
| 03 · Tender / Procurement Freeze | Reviewed configuration, scope boundaries and tender/BOQ requirements. | Align the BOQ, compliance/deviation notes, applicable documents and supply scope for commercial comparison. | Confirm open deviations, approval requirements and installation/acceptance interfaces before release for procurement. |
Coordinate installation against the agreed layout, mast/civil interfaces, electrical documents and aiming schedule. Record deviations for review by the responsible parties.
Agree the inspection and measurement approach and required handover records. Photometric acceptance does not replace structural, electrical or civil inspection.
Documents are released according to the confirmed project stage and agreed scope. Certificate and test-record applicability must be checked against the actual components and configuration. No fixed delivery time or universal approval responsibility is implied.
Use these paths to review the system, luminaires and structural interfaces in context.
Historical configurations show project-specific choices. They are not standard specifications for a new site.
Municipal parking-lot lighting
Port lighting
Large outdoor parking-lot lighting
Large-area lighting
Clarify the review basis before treating a configuration or document as final.
Start with the site/application, area dimensions or drawing, target zones, lighting criteria, preferred mast height or locations if specified, available wind/soil/power information, maintenance method and required documents. Missing non-final inputs can be identified during review.
There is no universal count. Area geometry, obstacles, target zones, mounting height, optics, aiming, maintenance factor, glare/spill-light limits and operational constraints must be reviewed together.
No. A height option may affect coverage, glare, structure, foundation loading, maintenance and installation. It must be compared against the actual project criteria.
No. The report must use the project geometry, targets, layout and an IES/LDT file matched to the selected luminaire, optic and BOM.
A foundation reference or interface drawing can be coordinated after the mast, wind, site and soil inputs are reviewed. Final construction design is project-specific and may require local approval.
No. Lowering and crane-maintenance paths should be compared against access, safety, operating capability and lifecycle requirements.
No universal coverage should be assumed. Selected real certificates and test records may be shown, while applicability to the selected luminaire, mast component, electrical scope and BOM is confirmed during project review.
Share the available layout and review requirements to identify the next engineering step.
Send the site plan, target zones, lighting criteria and known mast constraints. Include available wind, soil, electrical and maintenance information, plus any tender or document requirements.
