USA Rural Road Lighting Project (2024) — 7m Pole Package

A tender-style reference for rural road sections with documented assumptions and verification outputs.
Deliverables can be shared as a redacted pack (or under NDA) for EPC and consultant review.

Get Similar Configuration (24H)
Request Deliverables Pack
Luminaire Type AC LED Street Light
Power 70W LED
Optics IES Type III / wide beam (wide roadway distribution)
CCT / CRI 4000K (3000K / 5000K optional) / CRI ≥70
IP / IK IP66 / IK08 (IK09 optional)
Electrical PF ≥0.95 / THD ≤15%
Surge Protection 10kV standard / 20kV optional (luminaire SPD)
Pole Interface (7m) Single-side mounting / spigot Ø60mm (Ø76mm optional) / tilt 0–5°
Controls (Optional) Dusk-to-dawn (photocell / NEMA optional); dimming & smart-ready on request
Verification & Deliverables Spacing verified by IES + layout outputs; deliverables include IES + datasheet pack + BOQ matching notes (NDA support).

Technical Configuration (Project Reference)

This USA rural road lighting reference (2024) uses a 7m pole setup with a 70W AC LED street light and IES Type III wide distribution. Assumptions (mounting, interface, section spacing) are documented and linked to reviewer-ready deliverables: IES/LDT, layout outputs, and BOQ matching notes.
Technical Configuration (Project Reference)
  • ✓ Luminaire: 70W AC LED street light with IES Type III / wide distribution optics
  • ✓ Pole interface: 7m single-side mounting; spigot Ø60mm (Ø76mm optional) and tilt 0–5° documented
  • ✓ Performance reference: up to 200 lm/W (≈14,000 lm reference) with 4000K (3000K / 5000K optional), CRI ≥70
  • ✓ Protection: IP66 / IK08 with surge protection 10kV standard (20kV optional)
  • ✓ Controls: dusk-to-dawn operation; scheduled dimming optional; smart-ready NEMA/Zhaga on request
  • ✓ Verification & deliverables: IES + layout outputs + datasheet pack + installation checklist + BOQ matching notes (NDA support)

Scope & Assumptions

What this reference covers and the verification inputs documented for EPC review.
Scope (USA Rural Road — 7m Pole Package)
  • Coverage: rural road sections (single carriageway reference)
  • Use case: EPC / tender workflow requiring auditable assumptions
  • Deliverables referenced: IES/LDT + layout outputs + BOQ matching notes
  • Configuration approach: 70W AC LED + Type III optics with section-based spacing
Verification Inputs (Assumptions Documented)
  • Pole height: 7m (fixed for this reference)
  • Spacing: documented per section and verified by IES + layout outputs
  • Optics: IES Type III / wide distribution (road width coverage)
  • Targets: maintained lux & uniformity per project brief (simulation supported)
  • Controls: dusk-to-dawn; dimming profile optional (documented if required)
Detailed verification inputs can be shared in a redacted pack or under NDA for tender review.
Request Verification Inputs →

Photos & Acceptance Notes

Field photos confirm the deployment is real. The notes below summarize typical site acceptance checks used by EPC teams to reduce rework and sign-off risk.
Acceptance Notes (Typical)
✓
Bracket / Spigot Fit (7m Pole)
Verified against interface notes (Ø60mm spigot, arm length, tilt 0–5°).
✓
Wiring, Sealing & Polarity
Polarity checked before energizing; glands sealed and drip loop confirmed.
✓
Luminaire Orientation (Type III)
Type III distribution aligned to roadway direction for lateral coverage.
✓
Surge Protection & Grounding
SPD option confirmed (10kV / 20kV); grounding point and continuity verified.
✓
Electrical Check (Driver & PF)
Input and connections checked; driver spec and PF requirement verified for submission.
✓
Lux Spot-Check (Optional)
Performed on a representative section if required; recorded as a site note for review.
Tip: A redacted acceptance checklist and traceability notes can be shared for tender review (full records under NDA).

Deliverables Provided

Reference deliverables available for tender review and verification. Browse samples in the resource pages or request a project-ready pack.

IES / LDT Photometric Files

Browse IES files used for roadway optics verification and layout checks. Suitable for EPC submissions and audit trails.

View IES Library →

BOQ (Bill of Quantities)

Review BOQ examples aligned to scope, accessories, and configuration ranges for procurement and budgeting.

View BOQ References →

Drawings & Acceptance Checklist

Download or request CAD drawings, installation details, and datasheets for approvals.

View the Drawings →

DIALux / Relux Outputs

See report samples and typical verification items (maintained lux, uniformity, assumptions, and result tables).

View Report Samples →

FAQ (Tender & Verification)

Quick answers to common EPC / tender questions for this reference.
Can you share IES files for this 70W wide-optics configuration?
Yes. IES photometry for the 70W wide roadway distribution can be provided on request for layout verification and consultant review.
How do you determine spacing for 7m poles on rural roads?
Spacing is finalized by road width, setback, and target maintained lux/uniformity. We document assumptions and verify using IES + layout outputs when required.
Is 180VAC 50Hz supported for AC LED street lights?
Yes. Driver selection is matched to the site input requirement. Protection level and grounding method are confirmed based on project environment.
What optics is recommended for wider rural road sections?
A wide roadway distribution (Type III-style) is typically used to improve lateral coverage and reduce dark edges, then validated against layout assumptions.
What deliverables can you provide for tender verification?
Typical deliverables include datasheet, IES photometry, and BOQ alignment notes. Additional verification records can be shared in a redacted pack or under NDA.
